P5005C050S500H Product Overview
Product Category: Voltage Regulator
Use: The P5005C050S500H is a voltage regulator designed to maintain a stable output voltage under varying input conditions.
Characteristics: This voltage regulator is known for its high precision, low dropout voltage, and low quiescent current, making it suitable for a wide range of applications.
Package: The P5005C050S500H comes in a compact surface-mount package, allowing for easy integration into electronic circuits.
Essence: The essence of the P5005C050S500H lies in its ability to provide reliable voltage regulation in diverse electronic systems.
Packaging/Quantity: It is typically supplied in tape and reel packaging, with quantities varying based on customer requirements.
Specifications
- Input Voltage Range: 5.5V to 26V
- Output Voltage: 5V
- Maximum Output Current: 500mA
- Dropout Voltage: 300mV at 500mA
- Quiescent Current: 75µA
- Operating Temperature Range: -40°C to 125°C
Detailed Pin Configuration
The P5005C050S500H features a standard 5-pin configuration: 1. Vin (Input Voltage) 2. GND (Ground) 3. Enable (Shutdown Control) 4. Vout (Output Voltage) 5. NC (No Connection)
Functional Features
- Low Dropout Voltage: Ensures efficient operation even when the input voltage is only slightly higher than the desired output voltage.
- Low Quiescent Current: Minimizes power consumption in standby or idle modes.
- Thermal Shutdown Protection: Safeguards the regulator from overheating, enhancing its reliability.
Advantages and Disadvantages
Advantages: - High precision regulation - Wide input voltage range - Compact form factor
Disadvantages: - Limited maximum output current - Sensitive to input voltage fluctuations
Working Principles
The P5005C050S500H utilizes a feedback control loop to compare the output voltage to a reference voltage, adjusting the internal circuitry to maintain a constant output.
Detailed Application Field Plans
The P5005C050S500H is well-suited for various applications, including: - Battery-powered devices - IoT (Internet of Things) sensors - Portable consumer electronics
Detailed and Complete Alternative Models
- P5005C030S500H: Similar characteristics with a lower output voltage of 3.3V
- P5005C100S500H: Higher output current capability of 1A while maintaining the same input and output voltage specifications
In conclusion, the P5005C050S500H voltage regulator offers precise and reliable voltage regulation in a compact package, making it an ideal choice for a wide range of electronic applications.
